Band Cutter 부품
HOME > 제품안내 > Band Cutter 부품 > Band Cutter 부품
- Anvil Pin
- DWG No. D27992
- Size ; W230 x Φ25
- Anvil
- DWG No. ; D27990-1
- SIZE ; W167XD30XH94
- Anvil Support
- DWG No. ; C14659-1
- SIZE ; W200XD75XH152
- Back-Up Roll
- DWG No. ; C14660-1
- SIZE ; W245×D45.24×H45.24
- B.U.R Idle
- DWG No. D28000
- Size ; W21 x Φ50
- B.U.R Pinion
- DWG No. D28001
- Size ; W20 x Φ50
- B.U.R Idle Pin
- DWG No. D27995
- Size ; W245 x Φ25
- F.W Gear
- DWG No. D27998
- Size ; W38 x Φ70
- Fulcrum Gear
- DWG No. D27999
- Size ; W33 x Φ80
- Gear Case
- DWG No. C14656
- Size ; W267.5 x D195 x H48
- Gripper
- DWG No. ; D80926-1/2
- SIZE ; W78×D15×H15
- Idle Shaft
- DWG No. E31470
- Size ; W62 x Φ30
- Lower Guide
- DWG No. ; D33038-1
- SIZE ; W170XD53XH83
- Lower Knife
- DWG No. ; D43808
- SIZE ; W110×D25×H15
- Main Shaft
- DWG No. ; C14657-1
- SIZE ; W278xD65xH65
- Motor Pinion
- DWG No. D52657
- Size ; W85 x Φ55
- Motor Idle
- DWG No. D28797
- Size ; W31 x Φ70
- Pinion
- DWG No. ; E38850
- SIZE ; W68XD42XH42
- Upper Guide
- DWG No. ; D27993-1
- SIZE ; W170XD42XH47
- Upper Knife
- DWG No. ; D24244-1
- SIZE ; W115×D80×H36
- Φ40 Cylinder (Coiling Unit용)
- DWG No. : C18950
- Φ40 Piston (Coiling Unit용)
- DWG No. : E36110
- Φ40 Cover (Coiling Unit용)
- DWG No. : E36111
- Φ60 Cylinder (Coiling Unit용)
- DWG No. : D28002
- Φ60 Piston (Coiling Unit용)
- DWG No. : E30026
- Φ60 Cover (Coiling Unit용)
- DWG No. : E30027
